Description
Module kit descriptionOne: Common introduction to LCD panel:
Screen size 10.1″ screen type LCD module, a-Si TFT-LCD
Resolution 1366 (RGB) × 768
Display size 222.52 × 125.11 mm (H × V)
Appearance size 233.8 × 138.5 × 4.7 mm (H × V × D)
Visual size 224.92 × 127.41 mm (H × V)
Surface treatment mirror (Haze 0%), Hard coating (3H)
Brightness (cd/m2) 400 (Typ.)
Contrast 800 : 1 (Typ.) [Transmission]
Viewing angle 89/89/89/89 (Typ.) (CR 10) Left / Right / Up / Down
Response speed 13/12 (Typ.)(Tr/Td) ms
Quantity 262K/16.7M, 50% NTSC
Backlight type 10S3P WLED, 12K hours, with LED driver
Refresh frequency 60Hz. Built-in MEMC circuit touch function without touch
Signal system LVDS (1 ch, 6/8-bit), terminal, 40 pins
Supply voltage 3.3V (Typ.)
Maximum rated storage temperature: -20 ~ 70 °C Operating temperature: -10 ~ 60 °C
Two: drive motherboard and touch screen common instructions
The motherboard automatically recognizes the HMDI VGA DVI source
OSD language (Simplified Chinese, Traditional Chinese, English, French, German, Italian, Spanish, Portuguese, Japanese, Korean (optional))
Video input
Pc rgb format 2048×1152 @60hz
480 i, 480 p, 576 i, 576 p, 720 p, 1080 i, 1080 p
Audio Input PC Audio Headset Input 0.2 ~ 2.0 VRMS
Audio output; 8 ohms and 5W or less
Frequency response: 100 hz ± 3 ~ 15 kHz @ db (1 khz, 0 dB reference signal)
Power supply specification: 12 V1A (requires 12 v DC)
Screen voltage: 3.3 v / 5 v / 12 v adjustable
Management standby power consumption < 0.5 w
Touch common parameters:
Touch interface type: USB2.0/3.0
